川消消防軟管卷盤的概述以及功能
來源：http://www.xintli.net/ 日期：2023-02-14
川消消防軟管卷盤是一種滅火裝置，由閥門、輸入管、軟管、噴槍等組成。并能在迅速展開軟管的過程中噴灑滅火劑。發生火災時，消防人員用它來連接水管滅火。打開柜子，松開消防卷盤，接上水管，打開水閥，滅火。
Chuanxiao fire hose reel is a fire extinguishing device, which is composed of valve, input pipe, hose, spray gun, etc. The fire extinguishing agent can be sprayed during the rapid expansion of the hose. In case of fire, firefighters use it to connect the water pipe to extinguish the fire. Open the cabinet, loosen the fire reel, connect the water pipe, open the water valve, and put out the fire.
消防水帶卷盤又稱消防水帶卷盤，由線圈、軟管和銅矛頭組成。使用時可直接從線圈中抽出，方便易操作，主要用于撲滅初期火災。消防軟管由軟管、軟管接頭和水槍組成。需要兩個人來操作。把軟管放在一邊，一端接在消防栓的閘閥上，另一端接在水槍上，操作起來比較復雜，對滅火有重要作用。
Fire hose reel, also known as fire hose reel, is composed of coil, hose and copper spearhead. When in use, it can be directly pulled out of the coil, which is convenient and easy to operate, and is mainly used to put out the initial fire. The fire hose is composed of hose, hose connector and water gun. Two people are required to operate. Put the hose on one side, connect one end to the gate valve of the fire hydrant, and connect the other end to the water gun. The operation is complex and plays an important role in fire fighting.
消防軟管卷盤：酒店、重要寫字樓、一級商業建筑、會展建筑、綜合建筑等。其他建筑高度超過100米的高層建筑應設置消防卷盤，其用水量可不計入消防總用水量。消防卷盤之間的距離應保證水流能到達室內地面的任何部位，消防卷盤的安裝高度應便于接近、靈活、不卡死。火輪的插頭直徑應為25毫米;配備直徑不小于19mm的膠帶;卷盤消防噴嘴的直徑不小于6.00毫米。
Fire hose reels: hotels, important office buildings, first-class commercial buildings, exhibition buildings, comprehensive buildings, etc. Other high-rise buildings with a height of more than 100 meters shall be equipped with fire reels, and their water consumption may not be included in the total fire water consumption. The distance between fire reels shall ensure that the water can reach any part of the indoor ground. The installation height of fire reels shall be easy to access, flexible and not stuck. The plug diameter of the fire wheel shall be 25 mm; Provide adhesive tape with a diameter of not less than 19mm; The diameter of the reel fire nozzle shall not be less than 6.00 mm.
功能如下：
The functions are as follows:
消防卷盤直徑DN25.主要用于初期滅火。消防水帶直徑DN65.需要兩個人操作，主要用于中期火災。消防軟管卷盤：打開消防栓箱的門，然后將消防自救托盤對準右側，然后解鎖，調整角度。
The diameter of fire reel is DN25. It is mainly used for initial fire extinguishing. The diameter of fire hose is DN65. It needs two people to operate, and is mainly used for medium term fire. Fire hose reel: first open the door of the fire hydrant box, then align the fire self-rescue tray to the right, then unlock and adjust the angle.
左手握住卷盤的水槍頭，右手握住消火栓箱的門，輕輕拉出水龍帶，然后將水槍頭拉到著火點附近，再用一只手握住水槍頭。另一只手打開球閥噴水，均勻噴灑滅火水覆蓋著火點。確認火源已完全熄滅后，關閉水槍閘閥，返回消火栓箱，輕輕轉動水龍帶卷盤，將消防自救卷盤完全收回消火栓箱內，放置并關閉消火栓箱門，使用完畢。
Hold the water gun head of the reel with your left hand, hold the door of the fire hydrant box with your right hand, gently pull out the hose, then pull the water gun head to the vicinity of the ignition point, and then hold the water gun head with one hand. Open the ball valve with the other hand to spray water, and evenly spray the fire extinguishing water to cover the ignition point. After confirming that the fire source has been completely extinguished, close the water gun gate valve, return to the fire hydrant box, gently turn the hose reel, fully retract the fire self-rescue reel into the fire hydrant box, place and close the fire hydrant box door, and use it.
The above is the introduction of the fire hose reel. If you have any doubts or needs, please come to our website http://www.xintli.net Ask about it!
