懸掛式超細干粉滅火裝置的安裝與后期維護
來源：http://www.xintli.net/ 日期：2022-12-31
懸掛超細干粉滅火裝置安裝、維護簡便，深受業內人士歡迎。下面，
川消小編就為大家簡單介紹下懸掛式超細干粉滅火裝置在安裝和后期維護中應該注意哪些內容。
The suspended superfine dry powder fire extinguishing device is easy to install and maintain, and is welcomed by the industry. Now, Sichuan Xiaobian will briefly introduce what should be paid attention to in the installation and later maintenance of the lower suspended superfine dry powder fire extinguishing device.
一、懸掛式超細干粉滅火裝置的安裝方法
1、 Installation method of suspended superfine dry powder fire extinguishing device
1)用2個膨脹螺釘(M10)將固定支架固定在保護區上方的混凝預制板上，將滅火裝置上部吊環座旋入固定板下方的螺桿(M12)，深度不小于15mm，裝置安裝應牢固，不得松動。啟動模塊可以安裝在固定支架上。如圖4所示。
1) Use two expansion screws (M10) to fix the fixed support on the concrete precast slab above the protection area, screw the upper ring seat of the fire extinguishing device into the screw (M12) below the fixed plate, and the depth shall not be less than 15mm. The device shall be firmly installed without loosening. The starting module can be installed on the fixed bracket. As shown in Figure 4.
2)將1個帶鉤的膨脹螺釘(M12)固定在保護區上方的混凝預制板上，再將裝箱中吊環擰緊在滅火裝置上部，吊環鉤在膨脹螺釘彎鉤處，插上定位銷。啟動模塊可以掛在就近的墻壁或天花板上。如圖5所示。
2) Fix one expansion screw (M12) with hook on the concrete precast slab above the protection area, tighten the lifting ring in the box on the upper part of the fire extinguishing device, hook the lifting ring on the hook of the expansion screw, and insert the positioning pin. The startup module can be hung on the nearby wall or ceiling. As shown in Figure 5.
需要注意的是，訂貨時應注明吊裝方式，無特別說明時默認是吊環安裝。
It should be noted that the lifting method should be indicated when ordering, and the lifting ring installation is defaulted when there is no special instructions.
二、懸掛式超細干粉滅火裝置的維護
2、 Maintenance of suspended superfine dry powder fire extinguishing device
使用單位應建立維護管理制度，由專人負責定期檢查。建議每6個月少對滅火裝置進行一次檢查。滅火裝置一經開啟或發現壓力指示器指針指向紅色區域時，必須重新再充裝。
The user unit shall establish a maintenance management system, and special personnel shall be responsible for regular inspection. It is recommended to inspect the fire extinguishing device at least once every 6 months. Once the fire extinguishing device is opened or the pointer of the pressure indicator points to the red area, it must be refilled.
每12個月應進行一次綜合檢查，包括相關聯動系統。必要時，取下滅火裝置，檢查滅火劑是否有結塊現象，如果有，應該重新充裝。
A comprehensive inspection shall be conducted every 12 months, including relevant linkage systems. If necessary, remove the fire extinguishing device, check whether the extinguishing agent is caked, and if so, refill it.
此外懸掛超細干粉滅火裝置每次再充裝或每5年應對滅火劑粉罐進行水壓試驗。水壓試驗不合格不允許再使用。更多相關內容就來我們網站
http://www.xintli.net進行咨詢！
In addition, the superfine dry powder fire extinguishing device shall be suspended, and the water pressure test shall be carried out for the fire extinguishing agent powder tank every time it is recharged or every 5 years. It is not allowed to use again if the hydraulic test is unqualified. More relevant content will come to our website http://www.xintli.net Consult!
