泡沫鉤管的結構與使用說明
來源：http://www.xintli.net/ 日期：2022-09-16
泡沫鉤管，又叫低倍數空氣泡沫鉤管。它是一種移動式泡沫滅火設備，用于生產和噴射空氣泡沫，撲救沒有固定泡沫滅火裝置的地下，半地下和小型油罐的油類和汽油火災，也可以作為固定式泡沫滅火系統的補充。下面來講講
川消泡沫鉤管的結構與使用說明。
Foam hook pipe is also called low expansion air foam hook pipe. It is a mobile foam fire extinguishing equipment, which is used to produce and spray air foam to extinguish oil and gasoline fires in underground, semi underground and small oil tanks without fixed foam fire extinguishing devices, and can also be used as a supplement to fixed foam fire extinguishing systems. Next, the structure and operating instructions of Chuanxiao foam hook pipe will be introduced.
結構原理
Structural principle
是由鉤管和空氣泡沫產生器兩部分構成。鉤管上部有彎形噴管，用以鉤住著火的油罐上，并向罐內噴射泡沫，而下端為空氣泡沫產生器，裝有65毫米管牙接扣，用水帶連接，輸送空氣泡沫混合液。當泡沫混合液混合經過多孔錐管逐漸擴散，形成良好的空氣泡沫，從彎形噴管噴出，撲救火災，操作簡單方便。
The utility model is composed of a hook tube and an air foam generator. The upper part of the hook pipe is equipped with a curved spray pipe to hook the burning oil tank and spray foam into the tank, while the lower end is an air foam generator, equipped with a 65mm pipe thread connector, which is connected with a water belt to transport the air foam mixture. When the foam mixture is mixed and gradually diffuses through the porous cone tube, a good air foam is formed, which is sprayed from the curved nozzle to put out the fire. The operation is simple and convenient.
泡沫鉤管的使用說明：
Instructions for foam hook pipe:
在使用本產品時，應具備泡沫消防車或裝有空氣泡沫混合器的消防泵。
When using this product, foam fire truck or fire pump with air foam mixer shall be provided.
當油罐失火時，用水帶接通消防泵與空氣泡沫鉤管。
When the oil tank is on fire, the water hose is connected to the fire pump and the air foam hook pipe.
撲救高度超過5米的油罐火災時，應將空氣泡沫管栓裝在拉梯上，并將其升高，使噴口超過灌口高度后，緊靠罐壁；撲救地下或半地下油罐火災時，應將空氣泡沫鉤管移近油罐放在便于鉤掛的地方。
When putting out a fire in an oil tank with a height of more than 5 meters, the air foam pipe should be bolted on the ladder and raised so that the nozzle is close to the tank wall after exceeding the height of the nozzle; When fighting underground or semi underground oil tank fires, move the air foam hook pipe close to the oil tank and place it at a place convenient for hook.
待消防泵正常供水后，講水壓調整到空氣泡沫鉤管的工作壓力5公斤/厘米2，也可以在3-5公斤/厘米2壓力范圍使用，但混合量和空氣泡沫量相應變化。
After the fire pump supplies water normally, the water pressure shall be adjusted to the working pressure of 5 kg/cm2 of the air foam hook pipe, which can also be used within the pressure range of 3-5 kg/cm2, but the mixing amount and air foam amount shall change accordingly.
開啟控制空氣泡沫產生器進水和吸液管路得閥門。
Open the valve that controls the water inlet and suction lines of the air foam generator.
將空氣泡沫混合器的調節閥指針撥在“16”位置的泡沫混合液量示數上。
Put the pointer of the regulating valve of the air foam mixer on the foam mixture volume indicator at the "16" position.
待彎型噴管正常噴射泡沫后，將空氣泡沫鉤管在油罐上。
After the curved nozzle sprays foam normally, hook the air foam onto the oil tank.
本產品對于3%型和6%型的普通空氣泡沫液和氟蛋白泡沫均適用。
This product is applicable to 3% and 6% ordinary air foam concentrate and fluoroprotein foam.
此外空氣泡沫鉤管的另件應經常保持完整，放置在便于取用的地方，并防止被笨重物件碰壓。每次使用后，應檢查空氣泡沫鉤管內外漆層，若有脫落，應重新涂刷防水漆，防止銹蝕。更多注意事項就來我們網站
http://www.xintli.net進行咨詢了解吧。
In addition, the other parts of the air foam hook pipe should always be kept intact, placed in a place convenient for access, and prevented from being bumped by heavy objects. After each use, the internal and external paint layers of the air foam hook pipe shall be checked. If they fall off, the waterproof paint shall be repainted to prevent corrosion. More notes on our website http://www.xintli.net Ask about it.
