川消高壓二氧化碳滅火設備主要設備安裝
來源：http://www.xintli.net/ 日期：2022-07-14
①滅火劑瓶組及驅動氣體瓶組框架
① Fire extinguishing agent bottle group and driving gas bottle group frame
1、按設計要求，安裝滅火劑及驅動氣體瓶組架；
1. According to the design requirements, install the fire extinguishing agent and drive gas bottle assembly frame;
2、瓶組架牢固固定在地面上，必須打地腳螺栓，各連接部件安裝牢固防止震動和移位。
2. The bottle assembly frame is firmly fixed on the ground, foundation bolts must be installed, and all connecting parts must be installed firmly to prevent vibration and displacement.
3、應留有足夠的操作空間，使操作面距墻或兩操作面之間的距離不宜小于1m。
3. Enough operating space shall be reserved to ensure that the distance between the operating surface and the wall or between the two operating surfaces should not be less than 1m.
②滅火劑瓶組
② Fire extinguishing agent bottle group
1、將滅火劑瓶組與稱重裝置連接，懸掛于瓶組框架上，其安裝高度與方向應一致；
1. Connect the fire extinguishing agent bottle group with the weighing device, hang it on the bottle group frame, and its installation height and direction should be consistent;
2、瓶組上手動操作手柄應朝向操作面；
2. The manual operation handle on the bottle group should face the operation surface;
3、對瓶組進行編號
3. Number the bottle group
4、誤噴射防護帽出廠時配裝，以避免瓶組在轉運期間各種原因導致的誤噴放造成事故，因此瓶組未聯接管路前或維修檢查需斷開管路時應安裝該防護帽，拆下的防護帽應注意保存和保管。
4. The accidental spraying protective cap is assembled when leaving the factory to avoid safety accidents caused by accidental spraying caused by various reasons during the transportation of the bottle group. Therefore, the protective cap should be installed before the bottle group is not connected to the pipeline or when the pipeline needs to be disconnected for maintenance and inspection, and the removed protective cap should be preserved and kept.
③驅動氣體瓶組
③ Drive gas cylinder group
1、瓶組固定在瓶組架上，固定牢固；
1. The bottle group is fixed firmly on the bottle group frame;
2、電氣連接線應沿瓶組架或墻面固定，防止其他物體碰撞；
2. The electrical connection line should be fixed along the bottle rack or the wall to prevent other objects from colliding;
3、氣體驅動管路布置應橫平豎直，采用支架固定；
3. The gas drive pipeline shall be arranged horizontally and vertically, and fixed with supports;
4、低泄高封閥必須垂直地面向上安裝；
4. The low discharge and high seal valve must be installed vertically upward;
5、氣體驅動管路安裝完畢，應進密性能試驗，試驗壓力為6.0MPa,壓力保持5min不泄漏；
5. After the installation of the gas drive pipeline, the air tightness test should be carried out. The test pressure is 6.0MPa, and the pressure should be maintained for 5min without leakage;
6、誤噴射防護帽出廠時配裝，以防止瓶組在轉運期間各種原因導致誤啟動容器閥造成事故，因此瓶組未聯接管路前或維修檢查需斷開管路時應安裝該防護帽，拆下的防護帽應注意保存和保管。
6. The protective cap for mistakenly spraying is assembled when leaving the factory to prevent safety accidents caused by mistakenly starting the container valve due to various reasons during the transportation of the bottle group. Therefore, the protective cap should be installed before the bottle group is not connected to the pipeline or when the pipeline needs to be disconnected for maintenance and inspection, and the removed protective cap should be preserved and kept.
7、安裝完畢，驅動氣體瓶組正面應標明對應防護區名稱或編號。
7. After installation, the name or number of the corresponding protection zone shall be marked on the front of the drive gas cylinder group.
④電磁型驅動裝置
④ Electromagnetic drive
為確保，防止誤噴，電磁型驅動裝置應在系統驗收合格之后安裝，拔出保險銷方能正常使用。
In order to ensure safety and prevent accidental spraying, the electromagnetic drive device should be installed after the system passes the acceptance, and can be used normally only after the safety pin is pulled out.
⑤集流管及連接管
⑤ Collecting pipe and connecting pipe
1、集流管安裝在滅火劑瓶組框架上，調整位置后固定牢靠；
1. The collecting pipe is installed on the frame of the fire extinguishing agent bottle group, and fixed firmly after adjusting the position;
2、帶泄放裝置的集流管，泄壓口不應朝向操作面、走道和門等，以免泄壓時對人員造成傷害。
2. For the collecting pipe with safety relief device, the pressure relief port should not face the operating surface, walkway, door, etc., so as to avoid injury to personnel during pressure relief.
⑥選擇閥安裝
⑥ Selector valve installation
1、安裝高度不宜超過1.7m，其手動操作桿應朝向操作面；
1. The installation height should not exceed 1.7m, and its manual operating lever should face the operating surface;
2、安裝完畢，在操作桿附近標明防護區名稱或編號的性標志。
2. After installation, a permanent sign with the name or number of the protection area shall be marked near the operating rod.
⑦噴嘴安裝
⑦ Nozzle installation
1、外露部分應美觀，連接螺紋不應露出吊頂；
1. The exposed part shall be beautiful, and the connecting thread shall not expose the ceiling;
2、川消小編認為在安裝時應逐個核對型號、規格和噴灑方向，嚴格按設計要求。
2. Chuanxiao Xiaobian believes that the model, specification and spraying direction should be checked one by one during installation, and the design requirements should be strictly followed.
