川消中低壓消防泵產品應用范圍以及特點
來源：http://www.xintli.net/ 日期：2022-07-08
中低壓消防泵可完全替代普通低壓泵。它可以獨立輸出低壓水流、中壓水流和軟管水流，也可以同時輸出低壓水流、中壓水流和軟管水流，以便消防車在時間進行滅火。同時近距離。，還可以遠距離供水，也可以向高層供水，火災現場的機動性大大增強。那么我們來說說中低壓消防泵產品的應用范圍和特點。
The medium and low pressure fire pump can completely replace the ordinary low pressure pump. It can output low-pressure water flow, medium pressure water flow and hose water flow independently, and can also output low-pressure water flow, medium pressure water flow and hose water flow at the same time, so that the fire truck can extinguish the fire at the first time. At the same time, close., It can also supply water from a long distance or to high-rise buildings, which greatly enhances the mobility of the fire scene. Then let's talk about the application scope and characteristics of medium and low pressure fire pump products.
中低壓消防泵產品適用范圍：
Application scope of medium and low pressure fire pump products:
用于輸送不含固體顆粒的清水和物理化學性質與水相似的液體。主要用于消火栓、噴淋林、穩壓器等。輸送液體流量范圍0.42~333L/s，壓力范圍0.8~2.25mpa，配套功率范圍0.18~160KW，口徑范圍為15mm~400mm
It is used to transport clean water without solid particles and liquids with physical and chemical properties similar to water. It is mainly used for fire hydrants, sprinkler forests, regulators, etc. The conveying liquid flow range is 0.42~333l/s, the pressure range is 0.8~2.25mpa, the supporting power range is 0.18~160kw, and the caliber range is 15mm~400mm
中低壓消防泵產品特點
Features of medium and low pressure fire pump
1、結構緊湊、體積小、外形美觀。其立式/臥式結構決定了安裝面積小，其與泵腳中心重合，從而提高了泵的運行穩定性和使用壽命。
1. Compact structure, small volume and beautiful appearance. Its vertical / horizontal structure determines that the installation area is small, and its center of gravity coincides with the center of the pump foot, thereby improving the operation stability and service life of the pump.
2、運轉平穩、噪音低、部件同心度高。
2. Stable operation, low noise and high concentricity of components.
3、采用的水力模型，效率高，性能優良。
3. Advanced hydraulic model is adopted, with high efficiency and excellent performance.
4、軸封采用機械密封，具有耐磨、無泄漏、使用壽命長的特點。
4. The shaft seal adopts high-quality mechanical seal, which has the characteristics of wear resistance, no leakage and long service life.
5、泵的進出口在同一水平軸上，通徑規格相同，便于管路連接，裝卸極為方便。
5. The inlet and outlet of the pump are on the same horizontal shaft, with the same diameter specification, which is convenient for pipeline connection and loading and unloading.
6、維修方便，無需拆卸管路，只需拆下泵蓋螺母，取出電機及傳動部件即可進行維修。
6. It is convenient to maintain. There is no need to remove the pipeline. Just remove the pump cover nut and take out the motor and transmission parts for maintenance.
Chuanxiao explains the meaning of the fire pump model
XBD3.2/5-65L-160A
XBD3.2/5-65L-160A
XBD-消防泵組代號
XBD code of fire pump set
3.2-設計壓力（1/10MPa）表示揚程為32m
3.2-design pressure (1/10mpa) means the lift is 32m
5-設計流程（L/S）
5-design process (l/s)
65-進出口直徑（mm）
65 inlet and outlet diameter (mm)
L型結構是垂直的
L-shaped structure is vertical
160-葉輪公稱直徑（mm）
160 nominal diameter of impeller (mm)
A-葉輪切割
A-impeller cutting
