川消消防信息蝶閥沒有信號或信號長報處理
來源：http://www.xintli.net/ 日期：2022-07-01
如今，在消防工程中，消防信號蝶閥的使用越來越廣泛，但有時施工安裝方在安裝、施工、調試過程中偶爾會出現投訴。投訴內容基本是無信號、長信號等情況。讓我們找出以下情況。
Nowadays, in fire engineering, fire signal butterfly valve is used more and more widely, but sometimes the construction and installation party will occasionally complain during installation, construction and commissioning. The complaint content is basically no signal, long signal, etc. Let's find out the following.
消防信號蝶閥的信號是通過微動開關觸點的通斷原理實現的。微動開關本身質量問題導致的信號蝶閥故障可能會出現，但產品不合格的概率很低。要判斷是否是微動開關的質量問題，簡單的方法就是用萬用表測量，看看微動開關的阻值。
The signal of fire signal butterfly valve is realized through the on-off principle of microswitch contact. The signal butterfly valve failure caused by the quality problem of the microswitch itself may occur, but the probability of product failure is very low. To judge whether it is the quality problem of the microswitch, a simple way is to use a multimeter to measure and see the resistance value of the microswitch.
測量人員可以先用電表測量焊接連接的微動開關的一對觸點，記錄電阻值，然后用手指按動微動開關的觸點簧片，然后測量這對觸點，如果電阻值有變化，則可以判斷微動開關功能正常，質量沒有問題。如有必要，重復測試幾次以進行驗證。
The measuring personnel can first measure a pair of contacts of the microswitch connected by welding with an electric meter, record the resistance value, then press the contact reed of the microswitch with his finger, and then measure the pair of contacts. If the resistance value changes, it can be judged that the microswitch function is normal and the quality is OK. If necessary, repeat the test several times to verify.
如果能驗證微動開關功能正常，閥門啟閉信號仍不輸出，則可考慮信號蝶閥啟閉是否到位。無論是通過移動手柄來開啟和關閉閥瓣的信號閥，還是通過渦輪蝸桿驅動開啟和關閉閥瓣的信號閥，都是通過改變凹形凸輪的距離來實現信號輸出的。
If it can be verified that the microswitch function is normal and the valve opening and closing signal is still not output, it can be considered whether the signal butterfly valve is opened and closed in place. Whether the signal valve of the disc is opened and closed by moving the handle or the signal valve of the disc is opened and closed by driving the worm, the signal output is realized by changing the distance of the concave cam.
使微動開關的觸點打開和關閉。因此，遇到這種現象后，施工調試人員可以用萬用表在信號閥全關或全開的情況下進行測試。如果電阻表還是沒有變化，打開信號蝶閥傳動部分的防塵蓋，觀察凹形凸輪轉動時凹形凸輪與微動開關簧片的接觸距離。
Open and close the contacts of the microswitch. Therefore, after encountering this phenomenon, the construction and commissioning personnel can use a multimeter to test when the signal valve is fully closed or fully open. If the ohmmeter still does not change, open the dust cover of the transmission part of the signal butterfly valve and observe the contact distance between the concave cam and the reed of the microswitch when the concave cam rotates.
可能由于搬運、運輸、安裝操作不當，以及外力，如碰撞、振動等，使微動開關的距離發生偏移和變化，導致接觸不良。如果確認微動開關的距離偏移發生變化，調整固定微動開關的兩個小螺絲，適當調整微動開關的距離。凹形凸輪體隨凹凸面移動，使微動開關的觸點隨著凹凸面的變化而被按下（接通）或釋放（斷開）。
The distance of the microswitch may shift and change due to improper handling, transportation and installation, as well as external forces, such as collision and vibration, resulting in poor contact. If the distance offset of the microswitch is confirmed to change, adjust the two small screws that fix the microswitch and adjust the distance of the microswitch appropriately. The concave cam body moves with the concave convex surface, so that the contact of the microswitch is pressed (connected) or released (disconnected) with the change of the concave convex surface.
川消小編提醒您微動開關本身的問題或微動開關與凹形凸輪接觸距離造成的原因除外。應更加注意信號輸出或顯示系統的質量，因?yàn)樾盘?hào)輸出顯示系統的故障率普遍較高。如果這部分出現問題，應該對癥處理，不需要考慮信號蝶閥的問題。
Chuanxiao Xiaobian reminds you of the problem of the microswitch itself or the contact distance between the microswitch and the concave cam. More attention should be paid to the quality of signal output or display system, because the failure rate of signal output and display system is generally high. If there is a problem in this part, it should be treated symptomatically, without considering the problem of signal butterfly valve.
