川消消防軟管卷盤到底有怎樣的使用性能？
來源：http://www.xintli.net/ 日期：2022-06-28
消防軟管卷盤簡稱消防卷盤，由盤卷、軟管和銅槍頭組成。使用時直接從盤卷中拉出，方便、易操作主要針對初起火災滅火使用。那么您知道消防軟管卷盤到底有怎樣的使用性能嗎？
Fire hose reel is referred to as fire reel for short, which is composed of reel, hose and copper gun head. When in use, it is directly pulled out from the coil, which is convenient and easy to operate. It is mainly used for extinguishing fire at the beginning. Do you know what kind of performance the fire hose reel has?
噴射性能：軟管卷盤應按規定進行噴射性能測試，測試結果應符合有關規定。20±5℃時，蛋白質泡沫滅火劑的發泡倍數不小于6.0倍，25%液體洗脫時間不小于90s；合成泡沫滅火劑的起泡倍數不小于5.0倍，25%液體的消退時間不小于60s。
Spray performance: the hose reel shall be tested for spray performance as required, and the test results shall comply with relevant regulations. At 20 ± 5 ℃, the foaming multiple of protein foam extinguishing agent shall not be less than 6.0 times, and the elution time of 25% liquid shall not be less than 90s; The foaming multiple of synthetic foam extinguishing agent shall not be less than 5.0 times, and the extinction time of 25% liquid shall not be less than 60s.
密封性能：軟管卷盤應按規定進行密封性能測試。任何部位應無泄漏，軟管纏繞軸不應有明顯變形。
Sealing performance: the hose reel shall be tested for sealing performance as required. There shall be no leakage at any part, and the hose winding shaft shall be free of obvious deformation.
卷盤管道的耐壓性能：卷盤管道應按要求進行水壓試驗。管道的任何部分不得有明顯的變形。水壓試驗壓力為額定工作壓力的1.5倍。經耐壓試驗后，卷盤應能正常使用。
Pressure resistance of coiled pipe: the coiled pipe shall be subject to hydrostatic test as required. Any part of the pipe shall not have obvious deformation. The hydrostatic test pressure is 1.5 times of the rated working pressure. After the withstand voltage test, the reel shall be able to work normally.
耐腐蝕性能：軟管卷盤應按規定進行鹽霧腐蝕試驗。表面應無肉眼可見的分層、剝落或凹坑。經過鹽霧腐蝕試驗后，軟管卷盤應能正常工作。
Corrosion resistance: the hose reel shall be subject to salt spray corrosion test as required. The surface shall be free from visible delamination, flaking or pitting. After the salt spray corrosion test, the hose reel shall be able to work normally.
耐負荷性能：對于使用過程中外露的軟管卷盤，應按規定進行耐負荷性能試驗。試驗后，其密封性能應符合規定。
Load resistance: for hose reels exposed during use, load resistance test shall be conducted as required. After the test, the sealing performance shall meet the requirements.
結構要求：
Structural requirements:
軟管卷盤內通道內應有殘留滅火劑的措施。
There shall be measures to remove residual extinguishing agent in the channel in the hose reel.
卷盤轉動部分應能繞轉臂固定軸水平向外擺動，擺動角度不小于90°。
The rotating part of the reel shall be able to swing horizontally outward around the fixed shaft of the rotating arm, and the swing angle shall not be less than 90 °.
單人軟管卷盤應設有機構，以保證進水閥未打開時軟管不能展開。
The single hose reel shall be equipped with a safety mechanism to ensure that the hose cannot be deployed when the water inlet valve is not opened.
卷盤進水閥的啟閉方向應標明。順時針關閉。
The opening and closing direction of the reel inlet valve shall be marked. Close clockwise.
軟管與卷盤的連接應保證軟管在纏繞時。接頭附近的軟管沒有壓扁。
The connection between the hose and the reel shall ensure that the hose is wound. The hose near the connector is not flattened.
旋轉性能：對于單人使用的軟管卷盤，其旋轉的起始扭矩不應大于20N·m。其余軟管卷盤的啟動扭矩不應大于120N·m。
Rotation performance: for the hose reel used by a single person, the initial rotation torque shall not be greater than 20n · M. The starting torque of other hose reels shall not be greater than 120N · M.
外觀質量：
川消小編認為卷盤表面應做防腐處理。涂漆部位的漆層應均勻。
Appearance quality: Sichuan Xiaobian believes that the surface of the reel should be treated with anti-corrosion treatment. The paint layer on the painted part shall be uniform.
