川消消防雨淋系統的組成及各部安裝要點
來源：http://www.xintli.net/ 日期：2022-06-09
雨淋系統通常由三部分組成：火災探測驅動控制系統；自動控制組動作閥系統；帶開放式噴水器的自動噴水滅火系統。其中，火災探測傳輸控制系統可以使用火災探測器、傳輸管網或易熔合金鎖來啟動群動閥。火災探測器、輸電管網、易熔鎖控制是自動控制手段。
The deluge system usually consists of three parts: fire detection drive control system; Automatic control group action valve system; Automatic sprinkler system with open sprinkler. Among them, the fire detection transmission control system can use the fire detector, transmission pipe network or fusible alloy lock to start the group operated valve. Fire detector, power transmission pipe network and fusible lock control are automatic control means.
當使用自動裝置時，還應提供手動裝置作為備用。可使用群動閥系統自動控制，雨淋閥或雨淋閥加濕報警閥。雨淋系統可分為空管雨淋系統和充水式雨淋系統兩種。充水雨淋系統的滅火速度比空管雨淋系統快。
When automatic devices are used, manual devices shall also be provided as backup. Group valve system can be used for automatic control, deluge valve or deluge valve humidification alarm valve. The deluge system can be divided into air pipe deluge system and water filled deluge system. The fire extinguishing speed of water filled deluge system is faster than that of air pipe deluge system.
在實際應用中，可根據保護對象的要求選擇合適的形式。在實際應用中，雨淋系統可能有許多不同的組件，但它們的工作原理大致相同。雨淋系統采用開放式噴水器，因此在整個保護區內同時進行噴水。
In practical application, the appropriate form can be selected according to the requirements of the protected object. In practical application, the deluge system may have many different components, but their working principles are roughly the same. The deluge system adopts an open sprinkler, so it sprays water at the same time in the whole protection area.
當發生火災時，火災探測系統感應到火情，控制雨淋閥打開，連接水源和雨淋管網，灑水器噴水滅火。
In case of fire, the fire detection system senses the fire, controls the deluge valve to open, connects the water source and deluge pipe network, and sprays water with sprinklers to extinguish the fire.
濕式報警閥通常閥瓣前后水壓相同（水通過導管內的水壓平衡孔保持閥瓣前后水壓平衡）。由于閥瓣的重量與閥瓣前后水的總壓力不同，閥瓣處于關閉狀態（閥瓣上方的總壓力大于閥下方的總壓力核）。
Wet alarm valves usually have the same water pressure before and after the valve clack (water keeps the water pressure before and after the valve clack balanced through the water pressure balance hole in the conduit). Because the weight of the valve disc is different from the total pressure of the water before and after the valve disc, the valve disc is closed (the total pressure above the valve disc is greater than the total pressure core below the valve disc).
發生火災時，封閉式灑水器會噴水。由于水壓平衡孔來不及補水，報警閥上方的水壓下降。這時閥瓣前面的水壓大于閥瓣后面的水壓，所以閥瓣打開，立管和管道打開。同時，水沿著報警閥的環形槽進入延時裝置、壓力開關和液壓報警鈴，發出火警信號，啟動消防泵。
In case of fire, the enclosed sprinkler will spray water. As the water pressure balance hole is too late to make up water, the water pressure above the alarm valve drops. At this time, the water pressure in front of the valve disc is greater than that behind the valve disc, so the valve disc is opened, and the riser and pipeline are opened. At the same time, water enters the time delay device, pressure switch and hydraulic alarm bell along the annular groove of the alarm valve to send out a fire alarm signal and start the fire pump.
施工安裝要點
Key points of construction and installation
川消濕式報警閥、延時裝置和液壓報警鈴的安裝位置周圍應預留足夠的維修空間，以確保在短的停機時間內進行維修。報警閥離地高度為1.2m。
Sufficient maintenance space shall be reserved around the installation position of Chuanxiao wet alarm valve, time delay device and hydraulic alarm bell to ensure maintenance within the shortest shutdown time. The alarm valve is 1.2m above the ground.
液壓警鈴是濕式報警閥的主要部件。水警鈴應設在有人值守地點附近。與報警閥的連接管道直徑應為20mm，總長不應超過20m，安裝高度不應超過2m，并應有排水設施。
The hydraulic alarm bell is the main component of the wet alarm valve. The marine police bell shall be set near the attended place. The diameter of the connecting pipe with the alarm valve shall be 20mm, the total length shall not exceed 20m, the installation height shall not exceed 2m, and there shall be drainage facilities.
濕式報警閥、延時裝置和液壓報警鈴之間的安裝距離、安裝高度和管道直徑應保證其功能滿足相關要求。
The installation distance, installation height and pipe diameter between wet alarm valve, time delay device and hydraulic alarm bell shall ensure that their functions meet relevant requirements.
濕式報警閥、緩速器和液壓鐘罩應能使用常用工具進行安裝和現場維護。
The wet alarm valve, retarder and hydraulic bell housing shall be able to be installed and maintained on site with common tools.
濕式報警閥的控制區域根據口徑等參數而有所不同。
The control area of wet alarm valve varies according to the diameter and other parameters.
